Description
Application
The DN-50-CT4 single nozzle filling machine is a semi-automatic, high-precision filling system designed for water-based paints and architectural coatings. The single nozzle design significantly improves filling efficiency, making it ideal for paint manufacturers, coating producers, and chemical plants that require flexible multi-format production. Typical applications include water-based paints, latex paints, architectural coatings, and similar flowable liquid products. The single nozzle filling machine supports both EX and non-EX configurations, allowing it to adapt to different production environments and safety requirements.
Highlights
- High equipment stability and low failure rate;
- Integrated self-learning algorithms to continuously optimize filling accuracy and efficiency
- Different packaging specifications can be switched, suitable for personalized orders or multi-formula production;
- The filling speed can be controlled manually to avoid bubbles or spillage caused by rapid filling
- Stainless steel material, long service life
- 1.5-inch ARO diaphragm pump with bag filter
- Integrated design for easy mobility
Product Parameter
| Single nozzle with buffer tank | |
| Filling range | 5-20 L |
| Filling Speed | Approx.6 cans/min for 5L, approx. 4 cans/min for 10L, approx.3 cans/min for 20L |
| Filling accuracy | ±10g for (5–10) L, ±15g for 20L |
| Power Supply | AC 380 (customizable) |
| Rated Power | 0.8 Kw |
| Explosion Protection | Non-Explosion Proof / CNEX Explosion Proof Available |
| Filtering Trolley | 1.5 inch ARO pump, with bag filter |
| Machine Dimension | 3048*910*1385 mm |
| Filtering Trolley Dimension | 800*450*1000mm |
System Components
The DN-50-CT4 single nozzle filling machine system consists of:
Ensures precise liquid control
Intelligent and easy to operate
Real-time monitoring for accuracy
Smooth product transfer
The integrated workflow ensures efficient and stable production from start to finish.
Detail Photos & Videos
FAQ
What materials can the DN-50-CT4 single nozzle filling machine handle?
The Sightec DN-50-CT4 single nozzle filling machine handles water-based paints, architectural coatings, and viscous liquids up to 130 KU. It is not recommended for solvent-based or stone paint without a viscosity and pump configuration review.
Does the DN-50-CT4 single nozzle filling machine require an explosion-proof environment?
The Sightec DN-50-CT4 single nozzle filling machine can be manufactured to suit your safety requirements. We offer both EX (Explosion-proof) and Non-EX configurations depending on the volatility of the chemicals you are processing.
Can your machine offer customisation?
Our machine can be customised according to customer requirements.
